cnc router after sale service problem support

cnc router is computer control to engraver and cutting machine

just design what you want to cut or engraver on design software,so it can easy and automatic to finish engraver and cutting job.

so follows we are saying how to solve some of problem for cnc routers.

CNC engraving machine common fault analysis
◆ uniaxial or triaxial cnc router machine does not move around or walking is not normal
1 Control Carcassonne action or failure ; 2 drive failures corresponding axis ; 3 -axis stepper motor corresponding fault ; 4 corresponding coupling broken out or loose ( loose coupling manifestations , carving font dislocation ) ; 5 corresponding screw nut screw breakage or malfunction ; 6 -axis corresponds to the fast sliding failure ; 7 drives segments, current, and the software is not set up the same.

◆  cnc router machine z -axis control ( bar knife )
1 Control Carcassonne action or failure ; 2 static ; 3.z axis motor line failure ; 4 file path is incorrect ; 5 inverter interference ; 6 computer system problems or a virus ; 7.Z axis motor power enough, loose coupling ; 8.Z shaft drive current is too small , or signal lines are wrong .

◆ cnc router machine error
1 controls are loose or fault ; 2 drive failures ; .. 3 stepper motor failure ; 4 static ; 5 motor line failure ; 6 data line failure ; .. 7 path is wrong ; 8 coupling breakage or loose ; 9 processing speed is too fast ; ( system parameter curve acceleration is too large ) 10 computer system problem or a virus ) .

◆ cnc router engraving shades
1 Control Carcassonne action or failure ; 2 stepper motor failure ; 3 drive failure or software settings are inconsistent with the current subdivision ; 4.z axis motor line failure ; 5 spindle motor failure ; 6 inverter interference or data set . wrong ; 7 static ; 8 computer virus or system problems ; 9 working platform uneven .

◆ engraving machine carve
1 controller card failure ; 2 inverter interference ; 3 file path is incorrect ; 4 static ; 5 software provided with the problem ; 6 drive failure or current breakdown is set incorrectly ; 7 data line failure ; 8 computer virus or system problems.

◆ cnc router machine milling end injustice
1 vertical spindle and the table does not need correction ( presenting symptoms : the knife and sword of the shades ) ; 2 knives in question ; 3 control card problems ; 4.Z axis Z -axis screw drive or have a problem ...

◆ cnc router engraving machine spindle stop
1 spindle internal short circuit ; 2 current shield ; 3 inverter parameter settings are incorrect or own fault ; 4 controller card failure ; 5 main axis or data line shorted.

◆ engraving machine spindle rotation does not sound normal
1 inverter is set incorrectly ; 2 spindle does not turn ; 3 spindle itself has a problem ( bearing damage ) .
Conversely when walking or engraving machine
◆ Homing direction
1 change in Notepad document ; 2 wiring methods to modify the inverter ; 3 modify the motor direction Weihong software.

◆ cnc router machine not working Homing
1 in the opposite direction ; 2 controller card failure or loose ; 3 limit switches or data line failure ; 4 drive failure ; . Nearly five-step motor failure .
